Animal Cremation Incinerator Model A600

Model

A600


Feed Capacity

Average 30 kgs per feeding(animal)

Burning Rate

Average 10 kgs per hour(animal)

Voltage

220V

Power

0.59Kw

Fuel

Natural Gas or Diesel oil or LPG Gas

Burner

Italy Burner

Feed Mode

Manual Feeding

Fuel consumption (Oil)

10.0-16.0 Kgs/Hour

Fuel consumption (Gas)

10.0-15.0m3/Hour

External Dimensions

175 x 100 x 180cm (main body)

Internal Dimensions

130 x 70 x 65cm(Primary Chamber)

Waste combustion chamber

600Liters

Post Combustion Chamber

200Liters

Oil Tank Capacity

200 Liters or More(Optional)

Door Opening

50 x 60cm

Chimney

5.0M or More(Optional)

Gross Weight

3300kgs

Chamber Material

Refractory Concrete

Max. Heat Value

160,000Kcal/Hr.

Operation Technical Specifications

Solid Chamber temperature

800⁰C -1000⁰C

Gas Chamber temperature

1000⁰C -1200⁰C

Chamber Anti-Rate

1450⁰C

Residency time

2.0 Sec.

Burning efficiency

＞97%

Waste Lower Calorific Power

3000Kcal
